The television wall is the most-looked-at surface in most homes and one of the least designed. It usually ends up as a console with a screen above it, a visible cable loop, and a set-top box balanced somewhere it was never meant to be.
Here is how to plan a TV unit or media wall properly — the heights, the services, the storage, and how to make the screen less dominant when it is off.
Get the height right first
This is the most commonly made mistake in Indian homes, and it is permanent once the bracket is in.
The centre of the screen should sit at seated eye level — roughly 1,000 to 1,100mm from the floor for most people on a standard sofa. For a 55-inch screen that puts the bottom edge at about 650 to 700mm.
Almost every television in India is mounted higher than this, usually because it is placed above a console at a height that looks balanced on the wall. It looks fine and gives you neck strain over a two-hour film.
Never mount it above a fireplace. The viewing angle is wrong and the heat is bad for the screen.
And the distance
Viewing distance should be roughly 1.5 to 2.5 times the screen diagonal for 4K content. So:
- 55-inch — 2.1 to 3.5m
- 65-inch — 2.5 to 4.1m
- 75-inch — 2.9 to 4.8m
- 85-inch — 3.2 to 5.4m
Measure your actual seating distance before buying the screen. A 75-inch television at 2.5m is uncomfortable, and people buy it anyway because the showroom was enormous.
The services, planned at first fix
This is where a media wall is won or lost, and all of it has to happen before plaster:
- Power behind the screen — a socket at screen height, concealed by the television itself
- Power in the unit — for the set-top box, console, router, soundbar. More sockets than you think, on a separate circuit if you can
- A conduit between the two, minimum 50mm diameter, so HDMI and power cables can be pulled through later. This single item is the difference between a clean wall forever and a visible cable loop
- A data point behind the screen and in the unit. Wired is still better than wireless for streaming
- Ventilation in any closed compartment holding a set-top box or console. Sealed joinery cooks electronics
- Infrared line of sight, or an IR repeater, if the set-top box lives behind a solid shutter. A remote that only works with the cupboard open is a daily irritation
- Speaker cabling if you are wiring for sound — far easier now than later
A 50mm conduit costs almost nothing at first fix. Adding one afterwards means chasing a finished wall.
Making the black rectangle less dominant
A television off is a dark void in the middle of a wall. Three approaches work:
Recess it. A niche the depth of the screen plus its bracket, so the television sits flush with the surrounding surface. Cleanest result by a distance. Needs to be drawn accurately against the specific screen and bracket — measure the actual model.
Absorb it into a dark field. Make the whole panel behind and around the screen a dark material — deep veneer, a dark fluted panel, a textured stone. The screen stops being a hole and becomes part of a composition.
Give the wall something else to look at. Asymmetric joinery, a shelf with objects, lighting that grazes a textured surface. The eye then has somewhere to go that is not the screen.
What does not work: a light-coloured wall with a black rectangle in the middle of it and nothing else.
Storage: mostly closed
Living rooms accumulate — remotes, chargers, cables, board games, children’s things. A media wall with genuine closed storage is worth more than an open shelving composition that will be full of clutter within a year.
The arrangement that works: drawers or shuttered storage at low level for the accumulating things, a small ventilated compartment for devices, and limited display above — ideally behind glass in Delhi, where open shelves collect dust on everything.
Keep the low run shallow, 400 to 450mm, so it does not project into the room. Deep low units eat circulation and look heavy.
Lighting the wall
Do not put a downlight directly in front of the screen — it reflects.
What works: a soft wash behind the screen, either a strip in the recess or backlighting the panel, which reduces eye strain in a dark room and makes the unit look considered. Then accent light on any display or on a textured surface, and nothing pointed at the glass.
All of it dimmable and at 2700K, like everything else in the room.
Sound
Built-in television speakers are poor, and in a hard-surfaced Indian living room they are worse. A soundbar is the pragmatic answer — but plan for it: either a shelf at the right height that does not block the screen’s bottom edge or its sensor, or a slot in the joinery sized for the specific bar.
If you are wiring for in-ceiling or in-wall speakers, do it at first fix. Retrofitting means opening a finished ceiling.
What to avoid
Mounting the screen too high, which is the default error. A visible cable loop between screen and console. A set-top box in a sealed cupboard with no IR path and no ventilation. Glass shelves without an edge detail. High-gloss finishes on the wall behind, which reflect the screen. And building the recess before you have bought the television — dimensions vary by model, and a niche 20mm too small is a rebuild.
Getting it right
We draw media walls as joinery with the services planned in — conduit runs, socket and data positions, ventilation, IR path, speaker provision, and the recess dimensioned against the actual screen and bracket — because everything that makes this wall look clean happens before the plaster goes on.
If you are planning one, tell us about the room. See also living room planning, home theatre design, and how to judge joinery quality.
